Objectove Question & Answer :-
1- What is the name of artery?
(a) Facial
(b) Cardio
(c) Brachial
(d) Temporal
Answer - b
2- What does the symbol refer?
(a) Physical hazard
(b) Biological hazard
(c) Ergonomic hazard
(d) Noise and vibration
Answer - d
3- What is the term of the outermost layer of earth?
(a) Lithosphere
(b) Atmosphere
(c) Hydrosphere
(d) Thermosphere
Answer - a
4- Which is the most accepted method of avoiding accident?
(a) Wearing safety equipment
(b) Doing things in one’s own way
(c) Performing with highly skilled working practice
(d) Observing safety precautions related to job, machine and working place
Answer - d
5- What is Class D fire?
(a) Oil and fats
(b) Flammable liquids
(c) Combustible metals
(d) Energized electrical equipment
Answer - c
6- What is ABC of first aid?
(a) Aid, Break, Control
(b) Avoid, Bleeding, Control
(c) Airway, Breathing, Circulation
(d) Accident, Bleeding, Circulation
Answer - c
7- What is the percentage of oxygen in atmospheric gases?
(a) 78.03%
(b) 20.99%
(c) 15.88%
(d) 12.41%
Answer - b
8- How occupational disease caused in industrial environment?
(a) Negligence
(b) Lack of knowledge
(c) Improper handling of machines
(d) Persons exposed to substance or process
Answer - d
---------------------------------------------------------------------------------------
Name of the Trade : Draughtsman civil - 1st Sem - NSQF - Module 2 : Basic Engineering Drawing
1- What is the designation of 420 x 594 mm size paper as per BIS?
(a) A1
(b) A2
(c) A3
(d) A4
Answer - b
2- What is the part of a circle bounded by two radii on its arc?
(a) Circle
(b) Sector
(c) Segment
(d) Semi-circle
Answer - b
3- Which symbol represents double leaf double swing in window?
(a) A
(b) B
(c) C
(d) D
Answer - d
4- What is the name of the dimensioning arrangement?
(a) Chain dimensioning
(b) Parallel dimensioning
(c) Aligned dimensioning
(d) Unidirectional dimensioning
Answer - c
5- What is the name of scale?
(a) Plain scale
(b) Vernier scale
(c) Diagonal scale
(d) Comparative scale
Answer - b
6- What is the name of part labelled as X?
(a) Plug
(b) Fuse head
(c) Base charge
(d) Priming charge
Answer - d
7- What is the name of dressing of stone?
(a) Dragged finish
(b) Furrowed finish
(c) Reticulated finish
(d) Hammer dressed finish
Answer - b
8- Name the arrow pointed X in spacing of drawing sheet.
(a) Trimming edge
(b) Border
(c) Orientation mark
(d) Frame
Answer - a
9- What the arrow head X denotes?
(a) Battens
(b) Strips
(c) Ebony edge
(d) Holder
Answer - c
10- What is the part marked as X?
(a) Screw
(b) Head
(c) Blade
(d) Linkage
Answer - b
11- What is the angle between the stock / head and blade in T- square?
(a) 30°
(b) 45°
(c) 60°
(d) 90°
Answer - d
12- What is A4 designation for untrimmed size of drawing sheet?
(a) 450 x 625 mm
(b) 330 x 450 mm
(c) 240 x 330 mm
(d) 165 x 240 mm
Answer - c
13- What is the material for given symbol?
(a) Stone
(b) Partition block
(c) Cone
(d) Brick
Answer - b
14- Which is the object for given symbol?
(a) Rolling shutter internal
(b) Sliding door internal
(c) Sliding door external
(d) Rolling shutter external
Answer - d
15- Which BIS code no is recommended for folding of drawing sheets?
(a) IS 11664 - 1989
(b) IS 11664 - 1987
(c) IS 11664 - 1986
(d) IS 11664 - 1981
Answer - c
16- How many vertical folds come under A0 size trimmed drawing sheet?
(a) 5
(b) 6
(c) 7
(d) 8
Answer - b
17- What is the untrimmed size of A5 designation drawing sheet?
(a) 450 x 625
(b) 330 x 450
(c) 240 x 330
(d) 165 x 240
Answer -d
18- What is the size / height in mm for material list and dimensioning in drawings?
(a) 9 to 10
(b) 7 to 8
(c) 5 to 6
(d) 3 to 4
Answer - d
19- What is the description of E1 hidden outlines?
(a) Dashed thin
(b) Chain thin
(c) Dashed thick
(d) Chain thick
Answer - c
20- How the dimensions can be read in aligned system of dimension technique ?
(a) Left hand edge of drawing sheet
(b) Right hand edge of drawing sheet
(c) Top to bottom
(d) Bottom to top
Answer - b
21- What is the description of G1 in centre line?
(a) Chain thin
(b) Dashed thin
(c) Dashed thick
(d) Continuous thick
Answer - a
22- How the unidirectional system dimensions are placed in engineering drawing to read?
(a) From the top of the drawing
(b) From left side to right
(c) From the bottom of drawing
(d) From right side to left
Answer - c
23- What is the size / Height in mm for sub - titles of drawing?
(a) 3 - 5
(b) 6 - 8
(c) 9 - 10
(d) 11 - 12
Answer - a
24- What is the scale used generally in MAPS?
(a) 1:10⁸
(b) 1:10⁷
(c) 1:10⁶
(d) 1:10⁵
Answer - c
25- What is the R.F, if an actual length of distance 5 m represented by 25 mm length?
(a) 1:2000
(b) 1:200
(c) 1:20
(d) 1:2
Answer - b
26- What is the name of given scale?
(a) Plain
(b) Comparative
(c) Vernier
(d) Diagonal
Answer - d
27- Which scale is used to construct angles in absence of a protractor?
(a) Diagonal scale
(b) Comparative scale
(c) Chord scale
(d) Plain scale
Answer - c
28- What is the given scale?
(a) Plain scale
(b) Comparative scale
(c) Diagonal scale
(d) Vernier scale
Answer - b
29- What is the classification of igneous rock?
(a) Geological
(b) Physical
(c) Chemical
(d) Practical
Answer - a
30- Which lime is used for construction of masonry?
(a) Class D
(b) Class C
(c) Class B
(d) Class A
Answer - c
31- How many grades the ordinary port land cement is available as per IS specification?
(a) 2 grades
(b) 3 grades
(c) 4 grades
(d) 5 grades
Answer - b
32- What is the percentage of cement water proofer in powder form for all water refining structure?
(a) 13 to 15%
(b) 11 to 12%
(c) 06 to 10%
(d) 02 to 05%
Answer - d
33- What is the projection if the receding lines are drawn to ½ scale?
(a) Cavalier projection
(b) Cabinet projection
(c) Clinographic projection
(d) Axonometric projection
Answer - b
